GCP IAM Binding using Temporal and GoLang(Gin Framework)

Publisher : Sailor

Gin is the web framework written in Go(GoLang). Gin is a high-performance micro-framework that can be used to build web applications. It allows you to write middleware that can be plugged into one or more request handlers or groups of request handlers.

By the end of this tutorial, you will:

- Learn how to use Gin to create RESTful APIs (we will be doing GCP IAM Binding using GoLang and Temporal), and

- Understand the parts of a web application written in Go.

- Understand Goroutine and how it is useful.

- Understand Temporal WorkFlows and Activities.

- Understand Cloud SDK Client interactions in GoLang.

Prerequisites

For this tutorial, you will need GoLang, Temporal, docker, and postman installed on your machine.

Note: If you don’t have postman, you can use any other tool that you would use to test API endpoints.

List of Packages we are going to use:

github.com/gin-gonic/gin
github.com/sirupsen/logrus
go.temporal.io/sdk
google.golang.org/api

Goroutine

Goroutine is a lightweight thread in Golang. All programs executed by Golang run on the Goroutine. That is, the main function is also executed on the Goroutine.

In other words, every program in Golang must have a least one Goroutine.

In Golang, you can use the Goroutine to execute the function with the go keyword like the below.

Temporal

A Temporal Application is a set of Temporal Workflow Executions. Each Temporal Workflow Execution has exclusive access to its local state, executes concurrently to all other Workflow Executions, and communicates with other Workflow Executions and the environment via message passing.

A Temporal Application can consist of millions to billions of Workflow Executions. Workflow Executions are lightweight components. A Workflow Execution consumes few compute resources; in fact, if a Workflow Execution is suspended, such as when it is in a waiting state, the Workflow Execution consumes no compute resources at all.

main.go

package main

import (
   "github.com/gin-gonic/gin"
   "personalproject/temporal/worker"
)

func main() {
   r := gin.Default()
   channel1 := make(chan interface{})
   defer func() {
      channel1 <- struct{}{}
   }()
   go iamWorkFlowInitialize(channel1)

   r.POST("/iambinding", worker.IamWorkFlow)
   r.Run()
}

func iamWorkFlowInitialize(channel <-chan interface{}) {
   err := worker.IamWorker.Run(channel)
   if err != nil {
      panic(err)
   }
}

we will be running the temporal worker as a thread to intialize the worker and starting our Gin server in parallel.

Temporal Worker

In day-to-day conversations, the term Worker is used to denote either a Worker Program, a Worker Process, or a Worker Entity. Temporal documentation aims to be explicit and differentiate between them.

worker/worker.go

package worker

import (
   "go.temporal.io/sdk/client"
   "go.temporal.io/sdk/worker"
   "os"
)

const IAMTASKQUEUE = "IAM_TASK_QUEUE"

var IamWorker worker.Worker = newWorker()

func newWorker() worker.Worker {
   opts := client.Options{
      HostPort: os.Getenv("TEMPORAL_HOSTPORT"),
   }
   c, err := client.NewClient(opts)
   if err != nil {
      panic(err)
   }

   w := worker.New(c, IAMTASKQUEUE, worker.Options{})
   w.RegisterWorkflow(IamBindingGoogle)
   w.RegisterActivity(AddIAMBinding)

   return w
}

The IamBindingGoogle workFlow and AddIAMBinding Activity is registered in the Worker.

Workflow Definition refers to the source for the instance of a Workflow Execution, while a Workflow Function refers to the source for the instance of a Workflow Function Execution.

The purpose of an Activity is to execute a single, well-defined action (either short or long running), such as calling another service, transcoding a media file, or sending an email.

worker/iam_model.go

package worker

type IamDetails struct {
   ProjectID string `json:"project_id"`
   User      string `json:"user"`
   Role      string `json:"role"`
}

This defines the schema of the Iam Inputs.

worker/base.go

package worker

import (
   "bytes"
   "encoding/json"
   "fmt"
   "github.com/gin-gonic/gin"
   "io"
)

func LoadData(c *gin.Context, model interface{}) error {
   var body bytes.Buffer

   if _, err := io.Copy(&body, c.Request.Body); err != nil {
      customErr := fmt.Errorf("response parsing failed %w", err)

      return customErr
   }

   _ = json.Unmarshal(body.Bytes(), &model)

   return nil
}

LoadData function is used to Unmarshal the data that is recieved in the Api request.

worker/workflowsvc.go

package worker

import (
   "context"
   "go.temporal.io/sdk/client"
   "os"
)

var (
   IamSvc IamServiceI = &iamServiceStruct{}
)

type IamServiceI interface {
   IamBindingService(details IamDetails) error
}

type iamServiceStruct struct {
}

type iamServiceModel struct {
   client     client.Client
   workflowID string
}

func (*iamServiceStruct) IamBindingService(details IamDetails) error {
   cr := new(iamServiceModel)
   opts := client.Options{
      HostPort: os.Getenv("TEMPORAL_HOSTPORT"),
   }
   c, err := client.NewClient(opts)
   if err != nil {
      panic(err)
   }

   cr.client = c

   workflowOptions := client.StartWorkflowOptions{
      TaskQueue: IAMTASKQUEUE,
   }

   _, err = cr.client.ExecuteWorkflow(context.Background(), workflowOptions, IamBindingGoogle, details)
   if err != nil {
      return err
   }

   return nil
}

here is the service layer of the WorkFlow where there is an interface which implements the methods which is defined on the interface.

worker/workflow.go

package worker

import (
   "github.com/gin-gonic/gin"
   "github.com/sirupsen/logrus"
   "go.temporal.io/sdk/temporal"
   "go.temporal.io/sdk/workflow"
   "net/http"
   "time"
)

func IamWorkFlow(c *gin.Context) {
   var details IamDetails
   err := LoadData(c, &details)

   if err != nil {
      logrus.Error(err)
      c.JSON(http.StatusBadRequest, err)

      return
   }

   err = IamSvc.IamBindingService(details)
   if err != nil {
      logrus.Error(err)
      c.JSON(http.StatusBadRequest, err)

      return
   }

   c.JSON(http.StatusOK, err)
}

func IamBindingGoogle(ctx workflow.Context, details IamDetails) (string, error) {

   iamCtx := workflow.WithActivityOptions(
      ctx,
      workflow.ActivityOptions{
         StartToCloseTimeout:    1 * time.Hour,
         ScheduleToCloseTimeout: 1 * time.Hour,
         RetryPolicy: &temporal.RetryPolicy{
            MaximumAttempts: 3,
         },
         TaskQueue: IAMTASKQUEUE,
      })

   err := workflow.ExecuteActivity(iamCtx, AddIAMBinding, details).Get(ctx, nil)

   return "", err
}

A Workflow Execution effectively executes once to completion, while a Workflow Function Execution occurs many times during the life of a Workflow Execution.

The IamBindingGoogle WorkFlow has been using the context of workflow and the iamDetails which contains information of google_project_id, user_name and the role that should be given in gcp. Those details will be send to an activity function which executes IAM Binding.

The ExecuteActivity function should have the Activity options such as StartToCloseTimeout, ScheduleToCloseTimeout, Retry policy and TaskQueue. Each Activity function can return the output that is defined the Activity.

worker/activity.go

package worker

import (
   "context"
   "flag"
   "fmt"
   "github.com/sirupsen/logrus"
   "google.golang.org/api/cloudresourcemanager/v1"
   "google.golang.org/api/option"
   "os"
   "strings"
   "time"
)

func AddIAMBinding(details IamDetails) error {
   projectID := details.ProjectID
   member := fmt.Sprintf("user:%s", details.User)
   flag.Parse()

   var role string = details.Role
   ctx1 := context.TODO()
   crmService, err := cloudresourcemanager.NewService(ctx1, option.WithCredentialsFile(os.Getenv("GOOGLE_APPLICATION_CREDENTIALS")))
   if err != nil {
      logrus.Errorf("cloudresourcemanager.NewService: %v", err)

      return err
   }

   addBinding(crmService, projectID, member, role)
   policy := getPolicy(crmService, projectID)
   var binding *cloudresourcemanager.Binding
   for _, b := range policy.Bindings {
      if b.Role == role {
         binding = b
         break
      }
   }
   fmt.Println("Role: ", binding.Role)
   fmt.Print("Members: ", strings.Join(binding.Members, ", "))

   removeMember(crmService, projectID, member, role)

   return nil
}

func addBinding(crmService *cloudresourcemanager.Service, projectID, member, role string) {

   policy := getPolicy(crmService, projectID)

   var binding *cloudresourcemanager.Binding
   for _, b := range policy.Bindings {
      if b.Role == role {
         binding = b
         break
      }
   }

   if binding != nil {
      binding.Members = append(binding.Members, member)
   } else {
      binding = &cloudresourcemanager.Binding{
         Role:    role,
         Members: []string{member},
      }
      policy.Bindings = append(policy.Bindings, binding)
   }

   setPolicy(crmService, projectID, policy)

}

func removeMember(crmService *cloudresourcemanager.Service, projectID, member, role string) {

   policy := getPolicy(crmService, projectID)

   var binding *cloudresourcemanager.Binding
   var bindingIndex int
   for i, b := range policy.Bindings {
      if b.Role == role {
         binding = b
         bindingIndex = i
         break
      }
   }

   if len(binding.Members) == 1 {
      last := len(policy.Bindings) - 1
      policy.Bindings[bindingIndex] = policy.Bindings[last]
      policy.Bindings = policy.Bindings[:last]
   } else {
      var memberIndex int
      for i, mm := range binding.Members {
         if mm == member {
            memberIndex = i
         }
      }
      last := len(policy.Bindings[bindingIndex].Members) - 1
      binding.Members[memberIndex] = binding.Members[last]
      binding.Members = binding.Members[:last]
   }

   setPolicy(crmService, projectID, policy)

}

func getPolicy(crmService *cloudresourcemanager.Service, projectID string) *cloudresourcemanager.Policy {

   ctx := context.Background()

   ctx, cancel := context.WithTimeout(ctx, time.Second*10)
   defer cancel()
   request := new(cloudresourcemanager.GetIamPolicyRequest)
   policy, err := crmService.Projects.GetIamPolicy(projectID, request).Do()
   if err != nil {
      logrus.Errorf("Projects.GetIamPolicy: %v", err)
   }

   return policy
}

func setPolicy(crmService *cloudresourcemanager.Service, projectID string, policy *cloudresourcemanager.Policy) {

   ctx := context.Background()

   ctx, cancel := context.WithTimeout(ctx, time.Second*10)
   defer cancel()
   request := new(cloudresourcemanager.SetIamPolicyRequest)
   request.Policy = policy
   policy, err := crmService.Projects.SetIamPolicy(projectID, request).Do()
   if err != nil {
      logrus.Errorf("Projects.SetIamPolicy: %v", err)
   }
}

Google Cloud Go SDK is used here for actual iamBinding.

- Initializes the Resource Manager service, which manages Google Cloud projects.

- Reads the allow policy for your project.

- Modifies the allow policy by granting the role that you are sending in the request to your Google Account.

- Writes the updated allow policy.

- Revokes the role again.

Finally we need temporal setup using docker,

.local/quickstart.yml

version: '3.2'

services:
  elasticsearch:
    container_name: temporal-elasticsearch
    environment:
      - cluster.routing.allocation.disk.threshold_enabled=true
      - cluster.routing.allocation.disk.watermark.low=512mb
      - cluster.routing.allocation.disk.watermark.high=256mb
      - cluster.routing.allocation.disk.watermark.flood_stage=128mb
      - discovery.type=single-node
      - ES_JAVA_OPTS=-Xms100m -Xmx100m
    volumes:
      - esdata:/usr/share/elasticsearch/data:rw
    image: elasticsearch:7.10.1
    networks:
      - temporal-network
    ports:
      - 9200:9200
  postgresql:
    container_name: temporal-postgresql
    environment:
      POSTGRES_PASSWORD: temporal
      POSTGRES_USER: temporal
    image: postgres:9.6
    networks:
      - temporal-network
    ports:
      - 5432:5432
  temporal:
    container_name: temporal
    depends_on:
      - postgresql
      - elasticsearch
    environment:
      - DB=postgresql
      - DB_PORT=5432
      - POSTGRES_USER=temporal
      - POSTGRES_PWD=temporal
      - POSTGRES_SEEDS=postgresql
      - DYNAMIC_CONFIG_FILE_PATH=config/dynamicconfig/development_es.yaml
      - ENABLE_ES=true
      - ES_SEEDS=elasticsearch
      - ES_VERSION=v7
    image: temporalio/auto-setup:1.13.1
    networks:
      - temporal-network
    ports:
      - 7233:7233
    volumes:
      - ./dynamicconfig:/etc/temporal/config/dynamicconfig
  temporal-admin-tools:
    container_name: temporal-admin-tools
    depends_on:
      - temporal
    environment:
      - TEMPORAL_CLI_ADDRESS=temporal:7233
    image: temporalio/admin-tools:1.13.1
    networks:
      - temporal-network
    stdin_open: true
    tty: true
  temporal-web:
    container_name: temporal-web
    depends_on:
      - temporal
    environment:
      - TEMPORAL_GRPC_ENDPOINT=temporal:7233
      - TEMPORAL_PERMIT_WRITE_API=true
    image: temporalio/web:1.13.0
    networks:
      - temporal-network
    ports:
      - 8088:8088
networks:
  temporal-network:
    driver: bridge
  intranet:
volumes:
  esdata:
    driver: local

Export the environment variables in terminal :

export TEMPORAL_HOSTPORT=localhost:7233
export GOOGLE_APPLICATION_CREDENTIALS={{path of your SPN File}}

Run the docker-compose file to start the temporal :

docker-compose -f .local/quickstart.yml up --build --force-recreate -d

Perfect!! We are all set now. Let’s run this project:

go run main.go

And I can see an Engine instance has been created and the APIs are running and the temporal is started as a thread:

                    Running Gin server…

And Even the Temporal UI is on localhost:8088

Let’s hit our POST API:

The Workflow is completed and IamBinding is Done is GCP also.
